EAP600 Enterprise Access Point Indoor Wi-Fi6 AP(Global version)

InHand Networks SKU: EAP600-LITE
filler

Price:
€186,64

Overview

EAP600 Enterprise Access Point

The EAP600 is a high-performance indoor dual-band Wi-Fi6 AP product. With the powerful network access capability of Wi-Fi6, it provides highspeed and convenient wireless network access for small businesses, enterprise branches, hotels and other scenarios requiring wireless coverage.Comprehensive security features and intelligent software services provide secure and reliable service data links for wireless scenarios

Powerful Edge Computing, Multiple Industrial Protocols, Python programmable. VPN

Features

Embrace the new experience of Wi-Fi 6 networking

EAP 600 series supports 802.11b/g/n/ac/ax standard and supports dualfrequency concurrency. The maximum speed of 5GHz band is 2.4Gbps, and the maximum speed of dual-band concurrent is 2974Mbps. With strong Wi-Fi access capabilities, each band supports 8 SSIDs and up to hundreds of terminals to meet the needs of high-density wireless terminal.

Edge computing with 256MB Nand Flash, CPU ARM cortex-A8 600MHz, 256MB Ram DDR3

Supports Wi-Fi Portal for value-added services

The authentication portal page can prevent unauthorized users from accessing the network and ensure the security of network resources. At the same time, it can customize the authentication interface. Customers can display customized content to customers in the authentication field.

Modbus TCP EtherNET/IP, Modbus RTU ISO on TCP

Cloud-Powered Management for Distributed Sites

EAP 600 offers a streamlined solution for effortless and straightforward management. Its integration with InCloud Manager provides a unified cloud platform, enabling real-time control and monitoring of distributed site equipment. With easy accessibility, users can efficiently manage on-site equipment status, making the overall management process more convenient, efficient, and cost-effective. Establishing remote connections further enhances operational efficiency and maintenance capabilities, allowing users to swiftly maintain and monitor field equipment, diagnose issues, debug, program, respond to faults, and pinpoint problems in distributed field devices. This proactive approach helps minimize losses caused by device failures.

InGateway902 Industrial Edge Computing Gateway with Azure, AWS IoT Greengrass Qualified

Fast deployment, flexible networking

The EAP600 supports Mesh networking between APs,support for multiple working mode switching. Mesh networking: Multiple APs can form a network through mesh, each network can become a connection point, adding AP expansion network without rewiring, strong scalability; In difficult cabling scenarios, there is no need to rewire, and the deployment is more flexible. When one AP fails, other APs automatically adjust to ensure network stability.

Integrated SDK and access system APIs

Product Detail

IG902-H

Packaging List

IG902, WiFi antenna*2, LTE 4G antenna, Power Supply, Ethernet Cable

Certifications

InGateway502 industrial gateway certifications

EAP600 Software Specifications
Cloud Management
InCloud Manager Unified device access zero-touch remote deployment bulk upgrades, configuration deployment SD-WAN networking, Connector remote maintenance Two-factor authentication
Access Mode
Network access Static IP /DHCP
Network&Security
IP Protocol IPv4/IPv6*
BSSID Each band supports 8 SSIDs
VLAN&IP Support for custom Wi-Fi network IP address or VLAN ID
Wi-Fi Security WPA-PSK,WPA/Enterprise* (WAP/WAP2/WPA3)
Radio Setting Set the bandwidth and transmit power of the radio
Guest Access Provide visitors network designed for temporary users
Portal* Supports portal authentication modes such as Radius,mobile phone and facebook
MAC Filtering Support MAC address filtering based on black and white list
Mesh Support Mesh networking between APs
Visualization
Dashboard Overview of device information,interface status,traffic statistics,client access and alarms
Topology* Displays the AP upstream/downstream topology connection status
Client List Collect statistics on the traffic and connection duration of the client connected to the AP
Wi-Fi Experience Wi-Fi client quality analysis
Mode
Work Mode FAT-Routing Mode/ FAT-Bridge Mode
EAP600 Hardware Specifications
Position
Site High-performance indoor Wi-Fi6.The recommended access number is 150 and the coverage radius is 15 meters
Hardware Platform RAM 5
RAM 512 MB
FLASH 128 MB NAND
Ethernet Port 1* Gigabit Ethernet port
Bluetooth No
Button 1* Reset button
LED 4*LED(PWR/WAN/2.4G/5G)
Antenna 2*built-in dual-frequency antenna
Power
Power Supply 12V/1A DC;802.3 af PD
Radio Specs
Radio 2 x 2 MU-MIMO, dual-band concurrent maximum rate 2974Mbps 2.4GHz (802.11b/g/n/ac/ax), maximum speed 574Mbps 5GHz (802.11a/n/ac/ax) with a maximum speed of 2.4Gbps
Parameter 2.4G Radio: 802.11b:1,2,5.5 and 11 Mbps 802.11g:6,9,12,18,24,36,48 and 54Mbps 802.11n:HT20/ HT40: MCS0~MCS15 (400/ 800ns GI) 802.11ac VHT20/VHT40: MCS0 ~ MCS9(400/ 800ns GI) 802.11ax HE2
5G Radio: 802.11a:6, 9, 12, 18, 24, 36, 48 and 54Mb/s 802.11n:HT20/ HT40: MCS0~MCS15(400/ 800ns GI) 802.11ac :VHT20/VHT40/VHT80: MCS0 ~ MCS9(400/ 800ns GI) 802.11ax :HE20/ HE40/HE80/HE160: MSC0 ~ MCS11(800/ 1600ns GI)
Transmit Power 2.4GHz/5GHz:20 dBm
Dimensions & Installation
Dimensions 158mm * 158mm * 28mm
Installation Desktops, ceilings
Environment
Storage Temp -40 ℃~ 70℃
Operating Temp
0℃~ 45℃
Humidity
5~ 95%
IP Level
IP30
Certification
CE,IC,FCC
